| Component Model # | CM-DP2LSA-B (Purchase Additional Cameras) (Support) |
| Resolution | 1920 x 1080 (1080p) |
| Series | DP2 |
| Video Transmission Technology | AHD |
| Field of View | 80º |
| 2-Way Audio | No |
| Microphone | No |
| Speaker | Yes (1-Way Audio - Preset Voice Messages / Siren) |
| Night Vision Range | (up to) 100 ft. |
| Spotlight | Yes (1 per Camera) |
| Power Supply | 12V 2A (Purchase) |
| Min / Max Power In | Min 10V / Max 18V |
| Maximum Cable Length | 160 ft. (Purchase) |
| Video Connection Type | BNC |
| Weather-Resistant Rating | IP-65 |
| Operational Temperature Range | -4°F - 140°F |
| Regulation | FCC |
