| Troubleshooting |
| Component Model # | CM-FTN12LS-D |
| Resolution | 4000 x 3000 (12MP) |
| Camera Series | FTN12 |
| Compatible System(s) |
FTN8 Series BTN8 Series |
| Video Connection Type | Ethernet |
| Field of View | Horizontal 100º, Vertical 53º |
| 2-Way Audio | Yes |
| Siren | Yes |
| Night Vision Range | (up to) 100 ft. |
| Spotlight | Yes (2 per Camera) |
| Maximum Cable Length | 300 ft. Through Cat5E Cable |
| Weather-Resistant Rating | IP-65 |
| Operational Temperature Range | -4°F - 140°F |
| Regulation | FCC |
| Power Supply (see note below) | Power over Ethernet (POE) and Optional 12V 2A Power Adapter (Purchase) |
| This camera is powered via Ethernet cable. If the camera is extended too far from the recorder, you may need to power the camera locally using a power adapter. If so, please use the 12V adapter found here. Your camera’s label may have the wrong power requirements listed. DO NOT exceed 12 volts. |
